LIGHT ENGINE and DISPLAY
DLP® Type 1-chip DMD UHD
Image resolution 4K UHD (3840x2160 pixels): 8.3M pixels
Light Source and brightness(1) 450W lamp (dimmable) - up to 5.000 Ansi Lumens (in 2D mode)
Lamp life expectancy(2) 3000 hours typical in ECO mode
Adjustable iris 12 apertures memorized
HDR capability
SIM2 Perfect Fit
Lens Super high definition pure-glass lens with telecentric optics
Lens resolution 93 lines per millimeter
INSTALLATION
Lens Throw ratio (+/-5%) 1.36-2.68:1
Zoom & Focus Motorized with position encoders
Optical Shift +/-75% Vertical, +/- 30% Horizontal
ELECTRONICS AND CONNECTIVITY
Horizontal & vertical scan freq. 15-91kHz/24-120Hz
UHD @ 24/25/30/50/60/70/72/75 Hz
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA, UHD, 4K (4096x2160), 10 bit Full Channel Signal Board Video Processing
Color Calibration Live Colors Calibration software 2.0
INPUTS/OUTPUTS
Digital 1 x HDMI (v.2.0a - HDCP 2.2)
2 x HDMI (v.1.4a - HDCP 1.4)
1 x HDMI audio/video out (v.1.4a - HDCP)
1 x Display Port 1.2
Analog Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
Component - Analog YPbPr/RGBs/RGBHV
Control 2 x IR receivers
1 x LAN (RJ45)
1 x RS232 (D-sub 9 pin)
1 x USB (A type for FW upgrade)
Miscellaneous 2 x 12V 200mA output
GENERAL SPECIFICATIONS
Mains voltage range 100-240 +/-10% (48/62 Hz)
Projector Weight 32 Kg. / 70.5 lbs
Projector dimensions 528 x 197 x 525 mm (20.8” x 7.7” x 20.7”)
ACCESSORIES
Supplied Installation and User Manual
AC power cords
Remote control and batteries
Optional Projector ceiling bracket
Anamorphic lens systems (fixed or motorized)
(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in a totally dark test room, brand new lamp at full power, lamp’s native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification.
(2) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty.
Due to constant product development, specifications are subject to change without notice.
