Display Technology |
Single 0.55” XGA DC3 DMD chip DLP® Technology by Texas Instruments |
Native Resolution |
XGA 1024 x 768 |
Brightness - BRIGHT mode1 |
3000 ANSI Lumens |
Contrast |
3000:1 |
Noise Level |
29/31dB (STD/BRIGHT mode) |
Aspect Ratio |
4:3 Native, 16:9 Compatible |
Weight |
3.1 kg |
I/O Connectors |
Inputs: |
PC/Video: HDMI, 2 x 15 Pin D-sub (RGB/YPbPr), S-Video, Composite, 2 x Audio In - Jack/RCA, USB (remote mouse), Mircophone |
Outputs: |
VGA Out, Audio Out - Mini Jack, +12v Trigger |
Control: |
RS232, RJ45 |
|
Preset Mode |
Movie: |
Maximum contrast and Colour accuracy |
sRGB: |
Best Colour Reproductiion |
User: |
Memorises user's settings |
Presentation |
Default mode, perfect with computers or notebooks |
Bright |
For environments with high ambient light (Brighest image) |
Classroom |
1500 ANSI Lumens, perfect for installations with interactive whiteboards |
Blackboard |
Perfect for installations with blackboards |
|
Maximum Resolution |
UXGA 1600 x 1200 |
Computer Compatibility |
UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac |
Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p) |
Displayable Colours |
1.07 Billion |
Projection Lens |
F/2.8; f=7.017mm, Fixed Zoom |
Throw Ratio |
0.626:1 |
Projection Screen Size |
1.00 – 5.00m (39.34” – 196.71”) Diagonal 4:3 |
Projection Distance |
0.5 - 2.5 metres |
Horizontal Scan Rate |
15 - 91kHz |
Vertical Scan Rate |
25 - 85Hz (120Hz for 3D) |
Lamp Type/Lamp Life2 |
4000/3000 hours (STD/BRIGHT mode) |
Keystone Correction |
± 40° Vertical |
Audio |
10W |
Dimensions (W x D x H) |
306 x 243 x 113mm |
Remote Control |
Full function remote with direct source selecting |
Power Supply |
100-240V, 50-60Hz |
Power Consumption |
295W BRIGHT mode < 1W Standby mode, 205W STD mode < 1W Standby mode |
Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
Uniformity |
80% |
Security |
Security Bar, Kensington Lock, Password Protection |
Standard Accessories |
Lens Cover, AC Power Cord, VGA Cable, Infra Red Remote Control with Batteries, Quick Start Card, CD User Manual, Warranty Card |
Optional Accessories |
Wall Mount - OPCWM835 |
RoHS |
Compliant |
3D Support |
120Hz frame sequential 3D for resolutions up to 720P. 60Hz field sequential 3D for resolutions up to 480i. |
3D Viewing |
Requires Optoma DLP® Link™ active shutter glasses – sold separately |
3D Compatibility |
The 3D features of the EX610ST can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling
software. Currently the EW610ST does not support 3D TV broadcast systems, SKY in the UK or 3D Blu-ray, though support for these applications may be added in future using additional hardware. |
