Projection System: Epson 3LCD, 3-chip optical engine
Projection Method: Front / Rear / Ceiling mount
Product Color: White and Black
Driving Method: Epson Poly-silicon TFT Active Matrix, 0.74-inch wide panel with MLA
Projected Output: HD, 2D, 3D, 1080p
Pixel Number: 2,073,600 dots (1920 x 1080) x 3
Color Brightness (Color Light Ouput): 2400 lumens1
White Brightness (White Light Output): 2400 lumens1
Aspect Ratio:
- Native 16:9 widescreen
- Compatible with 4:3
Native Resolution: 1080p (1920 x 1080)
Resize: 16:10, 4:3
Lamp Type: E-TORL™ 230 W UHE
Lamp Life:
- ECO mode: Up to 5000 hours2
- Normal mode: Up to 4000 hours2
Throw Ratio Range: 1.34 – 2.87
Size (projected distance): 30" – 300"
Keystone Correction: Vertical: ±30 degrees (Manual)
Contrast Ratio: Up to 600,000:1
Color Reproduction: Up to 1.07 billion colors
Color Processing: 10 bit
Other
Display Performance: 1920 x 1080 native (1080p); HD, 2D, 3D, 2D to 3D conversion
Color Modes:
- 2D: Dynamic, Living room, Natural, THX, Cinema, B&W cinema
- 3D: Dynamic, Cinema, THX
Cinema Filter: Automatically adjusts to color mode;
(On: Natural/THX/Cinema/B&W Cinema;
Off: Dynamic/Living Room/3D Dynamic/3D Cinema/3D THX)
Auto Iris: Automatically adjusts to video source;
Off/On: High-speed or Normal, 2D and 3D mode
Super Resolution: 2D and 3D
Input Signal:
- Composite: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
- Component: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
- HDMI: TMDS
Terminal Inputs:
- 2 HDMI
- 1 RS-232c
- 1 RCA (composite)
- 3 RCA (component)
- 1 VGA D-sub 15 pin (computer input)
Terminal Outputs:
- Trigger On/Off (3.5 mm stereo jack)
- 12 VDC 200 mA (max.)
Computer Compatibility: PC, Mac®
Operating Temperature: 41° to 95° F (5° to 35° C)
Power Supply Voltage: 100 – 240 VAC ±10% , 50/60 Hz
Power Consumption:
- Lamp on 350 W, Lamp on (Eco) 280 W
Fan Noise: 22 dB – 32 dB
Security: Kensington Security Lock Port
WirelessHD Transmitter
Power Consumption: 11V 1.2A
Operating Altitude: 0 to 7500 ft
Storage Temperature: 14 °F to 140 °F (-10 °C to 60 °C)
Input: HDMI x 5, including 1 MHL enabled
Output: HDMI x 1, Optical Audio x 1, USB Type A x 1 (3D Glasses Charging)
Wireless: FCC Part 15 Subpart C 15.255
Safety: UL 60950-1 2nd edition (cTUVus Mark)
EMC: FCC Part 15B Class B
Wireless HD Type: Beam Forming WirelessHD 1.0b 60 GHz Band (QPSK, 16-QAM, BPSK) 2 ch and 3 ch
Dimensions: 6.9" x 5.0" x 2.0" (W x D x H)
