| Resolution: |
XGA (1024x768) |
| Display Device: |
LCD; 0.8" Inorganic PolySilicon active matrix TFT Panels x 3 |
| Brightness: |
6000 ANSI Lumens |
| Contrast Ratio: |
2000:1 |
| Video Signals: |
PAL/PAL-M/PAL-N/SECAM/NTSC/NNTSC4.43 |
| Aspect Ratio: |
4:3 |
| Number of Colors: |
16.7 million |
| Lamp: |
* |
| Typical Lamp Life: |
3,000 Hours |
| Lens: |
: f: 1.7-2.3; FL: 1.06-1.78 in (26.9-45.4 mm) |
| Throw Ratio: |
1.7 - 2.89:1 |
| Image Size: |
40-400 in. |
| Throw Distance: |
4.3-75.1 ft |
| Keystone Correction: |
up-to 50% Up or Down/up-to 10% Left or Right |
| Projection Methods: |
Front / Rear / Ceiling |
| Inputs: |
On Input 2 - 5 BNC - Analog Computer (RGBHV) or Analog Video (Y,Pb/Cb,Pr/Cr) (BNC x 3)
On Input 3 - 4 pin DIN (S-Video) x 1 - S-Video x 1
On Input 3 - RCA x 1 - Composite Video x 1
Audio Signal Input (1) - Computer 1 & 2 / Component: Ministereo x 1
Audio Signal Input (2) - Computer 1 & 2 / Component: Ministereo x 1
Dsub9 x 1 -RS-232 Control Port
Dsub15 x 1 (#2) - Monitor Out
Dsub15 x 1 - Analog RGB
DVI-D x 1 - Digital Computer / Video w/HDCP
MiniStereo x 1 #2 - Audio Out (Variable)
MiniStereo x 1 - Wired Remote Control
RJ45f -Wired LAN Port
RCA x 2 (L & R or red & white) #3 - Audio In for Composite & S-Video
USB (series B) x 1 - Mouse Control |
| Outputs: |
Audio Output (Stereo) - Variable Line - MiniStereo x 1 |
| Speaker: |
Mono: 7 Watts RMS |
| Audible Noise: |
31 dBA |
| Weight: |
21.6 lb |
| Dimensions: |
19.27 x 17.12 x 6.46 in. |
| Accessories: |
Quick Start Guide, Owner's Manual on CD-ROM, AC Power Cord, VGA-type Computer Input Cable (Dsub15 - Dsub15), Remote with Mouse Control & Laser Pointer & Batteries (AAA x2). |
| Remote Control: |
Yes |
| Mfg Warranty: |
3 Years/6000 Hour - Whichever comes first. Lamp: 90 Days |
