| Brightness |
- Dual lamp: 12,500 ANSI lumens(14,000 centre lumens)
- Single lamp: 6,250 ANSI lumens (7,000 centre lumens)
|
| Contrast |
- 2,100:1 (full on/off) 650:1 ANSI (typical)
|
| Uniformity |
- 90% brightness uniformity
|
| Display type |
|
| Resolution |
|
| Lamp type |
|
| Lamp life |
- High power: 1000 hrs @ 450W
- Low power: 1500 hrs @ 360W
|
| Standard inputs |
|
| Optional inputs |
- Dual-link DVI
- Dual SD/HD-SDI
- Video decoder
- Twin HDMI
- Analog (5 BNC)
- DMX512 interface
|
| Input signals (2D) |
- HDTV formats VGA through to QXGA (2048 x 1536)
- Accepts all current HDTV/DTV formats
- Multi-standard video decoder
- Horizontal and vertical scaling, all inputs
|
| Input signals (3D) |
- Native 3D |48-60Hz per eye
- Frame doubled 3D | 24-30Hz per eye
- Dual input 3D | 48-60Hz per eye
- HDMI1.4a | Frame packed and Side-by-Side Horizontal
|
| Pixel clock |
|
| Scan rates |
- Horizontal: 15 to 120kHz
- Vertical: 23.97 to 150Hz
|
| Inputs, control & networking |
- RS232 in/out
- RS422 in
- Ethernet (10/100)
- GPIO (RS232 9-pin male connector)
- Built-in backlit LCD keypad
- Remote control (with optional wired XLR connection)
|
| Fixed lenses |
- ILS Lens 0.67:1 WU*
- ILS Lens 1.1:1 WU
|
| Zoom lenses |
- ILS Lens 1.16-1.49:1 WU**
- ILS Lens 1.4-1.8:1 WU
- ILS Lens 1.8-2.6:1 WU
- ILS Lens 2.6-4.1:1 WU
- ILS Lens 4.1-6.9:1 WU
- ILS Lens 6.9-10.4:1 WU
|
| Offsets |
- All lenses ±112% Vertical ±54% Horizontal except those noted below
* 0.67:1 fixed lens ±22%V ±6%H ** 1.16-1.49:1 zoom lens ±82%V ±38 %H
|
| Standard accessories |
- IR remote
- Power cord
- GPIO 3D sync cable
|
| Optional accessories |
- Coarse dust filter
- Fog juice filter
- Ceiling mount
- Ceiling mount extension
- ILS lens adapter kit
- Stacking frame
- Christie AutoStack™ (optional curve module available)
|
| Enhanced feature sets |
- LiteLOC™
- Comprehensive Color Adjustment (CCA™)
- Embedded Christie Twist™ image warping and edge-blending
- Intelligent Lens System (ILS™) for zoom, focus, horizontal and vertical offset for all lenses
- Auto setup
- Digital keystone correction
- Menus in five languages
- 99 channel memories
- Black level blending
- Built-in portrait display capabilities
|
| Operating voltage |
|
| Operating current |
|
| Power |
|
| Dissipation |
|
| Size |
- (LxWxH): 22.1 x 19.7 x 10.2" (561 x 500 x 259mm)
|
| Shipping dimensions |
- (LxWxH): 29.0 x 27.0 x 24.6" (737 x 689 x 625mm)
|
| Weight |
- 55lb (25kg) (without lens)
|
| Shipping weight |
|
| Operating environment |
- Temperature: 40 to 104°F (5 to 40°C)
- Humidity: 20-80% non-condensing
|
| Regulatory approvals |
- Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE); Regulation (EC) No. 1907/2006 (REACH)
- CAN/CSA C22.2 No. 60950-1
- UL 60950-1
- IEC 60950-1
- FCC, Part 15, Subpart B, Class A
- EN55022/CISPR22 Class A
- EN55024 / CISPR24
- Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC (Korea), PSE (Japan), C-Tick (Australia & New Zealand), South Africa
|
| Limited warranty |
- 3 years parts and labour (including light engine)
- Contact an authorised Christie representative for full details of our limited warranty
|
