| Image |
- 800 lumens ANSI
- 10,000:1 dynamic contrast (under LED control) - No mechanical iris required
- 95% brightness and colour uniformity after electronic adjustment
|
| Display Technology and Resolution |
- Revolutionary solid state projector using a single TI Darkchip 3™ DMD with a solid state illumination engine (no colour wheel) and sealed optics
- Native 2560 x 1600 WQXGA
- True 120Hz 3D (60Hz per eye content) or 120Hz via frame doubled content (30Hz per eye)
|
| Input |
- Signals: Up to 2560 x 1600 WQXGA1
- 2560 x 1600 @ 60Hz x 2 frame-locked with Dual input 3D for true 120Hz (60Hz per eye 3D), or
- 2560 x 1600 @ 60Hz x 1 for frame doubled output to 120Hz2
|
| Inputs, Control & Networking |
- External PC is required for projector operations via Ethernet
- Additional Ethernet connections for Christie ArrayLOC™ network
- 2 x xRS-232 ports
- 1 x RS-422 port
- 2 x Dual-link DVI-D
|
| Optical system |
Lens mount
- Mechanical, horizontal and vertical lens shift
- No shutter required
- No iris required – user programmable illumination parameters (eliminates the need for a mechanical shutter)
Illumination
- Solid state illumination
- Illumination lifetime greater than 50,000 hours (to 50% output)
Christie ArrayLOC™
- Manages the brightness and colour levels of all projectors within an array to a common level, in real-time with no additional latency
|
| Lenses |
Fixed
- 0.68:1 WQXGA lens
- 0.80:1 WQXGA lens
Zoom
Offsets
- 0.68:1 lens features ±5% (horizontal) and ±15% (vertical) offset when mounted in landscape orientation3
- 0.80:1 lens features +100%/-60% (horizontal) and +150%/-100% (vertical) offset when mounted in landscape orientation3
- 1.28-1.71:1 lens features +100%/-60% (horizontal) and +150%/-100% (vertical) offset when mounted in landscape orientation3
|
| Standard accessories |
- Line cord
- Christie Twist™4 optional
- User kit (icludes manual, IR remote)
- Christie AutoCAL™4
- Chrstie Twist Pro™4
- Rugged motion platform kit5 to withstand 5g shock load (purpose-built)
- Ruggedised transit case
- Remote IR sensor
- Christie MotoBlend™ optical blending6
|
| Enhanced feature sets |
- Minimum Processing Latency (MPL™)
- Auto power up
- Menus in 5 languages
- Christie ArrayLOC™ – automatic, continuous management of brightness and color space levels of all projectors in an array to a common level, in real-time
|
| Power requirements |
- Operating voltage: 100-240 VAC 50/60Hz
- Operating current: 10A max 100-120VAC, 5A 200-240VAC (lower in normal operational modes)
- Dissipation: 2316 BTU/hr max. (lower in normal operational modes)
|
| Dimensions |
- Size: 15.8" x 15.8" x 16.0" (400 x 400 x 406 mm) without lens
- Weight: 88.2lbs (40kg) without lens
- Shipping weight: 176.4lbs (80kg) without lens
|
| Operating Environment |
- Temperature: 40-95°F (5-40°C)
- Humidity: 20-80% non-condensing
- Portrait and landscape orientation
|
| Regulatory Approvals |
- Directives (EC) 2011/65/EU (RoHS)
- 2011/19/EU (WEEE)
- Regulation (EC) No. 1907/2006 (REACH)
- CAN/CSA C22.2 No. 60950-1
- UL 60950-1
- IEC 60950-1
- FCC, Part 15, Subpart B, Class A
- EN55022 / CISPR22 Class A
- EN55024 / CISPR24
- ICEES003 / NMB003 (A)
- Certifications marks and product approvals (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC (Korea), PSE (Japan), C-Tick (Australia & New Zealand); South Africa; Mexico
|
| Warranty |
- 2 years parts and labour (inclusive)
- Extended warranty options available
- Contact an authorised Christie representative for full details of our limited warranty
|
