| Image |
- 5000 ANSI lumens
- 1000:1 full on/full off
- 80% brightness uniformity (corner to corner)
|
| Display Technology |
- 3 x 0.8” Polysilicon TFT active matrix type Inorganic LCD
- XGA 1024 x 768 resolution
|
| Lamp |
- Single 275W NSHA lamp
- Typical life – Normal mode: up to 2000 hours; Eco mode: up to 3000 hours
|
| Signal Compatibility |
- UXGA
- WXGA
- SXGA+
- SXGA
- XGA
- SVGA
- VGA
- MAC
- HDTV formats (720P@60, 720P@50, 1080i@60, 1080i@50, 1035i, 1080p)
|
| Pixel Clock |
- 140 MHz (analog input) / 162MHz (digital)
|
| Scan Rates |
- Horizontal frequency 15 – 100 kHz
- Vertical frequency 48 – 100 KHz
|
| Inputs, Control and Networking |
- Input #1 – DVI-D x 1(Compatible with HDCP), D-Sub15 x1
- Input #2 – BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite)
- Input #3 – S-Video (Mini DIN 4-pin) , RCA x 3 (Video/Y , Pb/Cb , Pr/Cr)
- Audio In – Mini jack x 2 (1, 2)(stereo) , RCA x 2 (R, L-mono)
- Control port – Dsub-9 x 1
- R/C Jack – Mini jack x 1 (Wired remote)
- Network (LAN) - RJ-45 x1 (wired LAN)
|
| Outputs |
- D-Sub15 (Monitor out) x 1
- Audio out– Mini jack x 1 (stereo)
|
| Optical System |
- Motorized zoom, focus and lens shift
- Vertical and horizontal lens shift*
- Mechanical Light Shutter
- Bayonet style 1 button release lens mount
|
| Lenses |
- Ships with standard lens – Standard 1.70-2.89:1
- Fixed 0.8:1
- Short 1.25-1.70:1
- Long 2.89-4.60:1
- Long 4.60-7.36:1
- Offsets: Horizontal - 50%*; Vertical - 10%*
- * Actual range depends on lens used
|
| Standard Accessories |
- Quick setup manual
- PIN code Label Registration card
- UL cable card
- Lens adaptor
- Power cord-AC cord UL type (NEMA 6-20P plug type) 3 meters
- AC cord (European 2P plug type) 3 meters
- Computer cable (Dsub15)
- Owners Manual (CD-ROM)
- Remote control
- AAA Battery x 2
- Lens mount cover
- Lens anti-theft screw
- USB Cable
|
| Optional Accessories |
- CCM-LX for enhanced network options
- AutoFilter cartridge
- Replacement lamp
|
| Enhanced Feature Sets |
- 10-Bit image processing
- Top loading lamp
- 1-button quick lens release
- Digital keystone h/v
- 3D Keystone™ technology
- New easy menu navigation
- AutoFilter cartridge technology - up to 13,000 hour
- 360 degree on axis rotation
- Expansion port for advance networking module (CCM-LX)
- Customized logo capture
|
| Power Requirements |
- Operating voltage: 100 - 120 V AC +/- 10%; 200-240 V AC +/- 10%
- Operating current: Inrush current - 30A (AC100V); 60A (AC276V); Current rating- 5.2A (AC100V); 2.5A (AC200V)
- Power: 423W Max. (Normal 100V); 400W Max.(Normal 200V); 0.4W (Eco Stand-by 100V); 0.6W (Eco Stand-by 200V)
- Dissipation: 1,375 BTU/hr max
|
| Dimensions |
- Body dimensions, with STD lens (LxWxH):
- 17.12" (L) x 19.27"(W) x 6.50" (H);
- 434.8 (L) x 489.5 (W) x 164.0(H) mm
- Weight: 21.4 lbs/9.7Kg (with standard lens)
- Packaging size:
- 22.90" (L) x 26.81" (W) x 12.52" (H);
- 581.0 (L) x 681.0 (W) x 318.0 (H) mm
- Shipping weight: 34.8 lbs/15.8Kg
|
| Operating Environment |
- Noise: 38dBA; 31dBA Eco mode
- Operating temperature: 5°C to 40°C; 41°F to 104°F
- Altitude: 0 to 2700 m; 0 to 8858 feet
- Humidity (non-condensing): 20% to 80%
- Storage temperature: 14F to 140F / -10°C to +60°C
|
| Regulatory Approvals |
- This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):
- FCC Part 15, Subpart B Class B
- CISPR22/EN55022
- CISPR24/EN55024
- UL 60950-1 first edition
- IEC60950-1:2001
- 2002/95/EC RoHS
|
| Warranty |
- Projector: 3 years parts and labor
- Lamp: 500 hours or one year (whichever comes first)
- Contact an authorized Christie representative for full details of our limited warranty
|
