• Brightness: 5,000 ANSI lumens
• Contrast: Up to 3000:1

• 3 x 0.63" inorganic LCD
• 1024 x 768 native XGA

• 245W UHP lamp
• Normal mode 2500 hours, eco mode up to 4000 hours

• UXGA/SXGA+/SXGA/WXGA/XGA/WXGA/SVGA/ VGA, MAC16", NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, 480I, 480P, 576I, 720P, 1080i 1080p

• Horizontal: 15-106kHz
• Vertical: 56-120Hz

• 162 MHz (digital and analog)

• Input 1: D-Sub 15 x 1 (Component support)
• Input 2: 5-BNC (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite)
• Digital inputs: HDMI x 2, S-video DIN 4-pin x 1, Composite video RCA x 1
• Component video RCA x 3, USB input type A x 2 for optional wireless network), USB type B x 1 (for USB display or mouse control), Audio In - Mini jack x 2 (3.5 mm stereo), RCA jack (L,R) x 1
• Output RCA (L & R) x 1, Network (LAN) RJ-45 x 1 (wired LAN), Control terminals 9-pin D-sub x 1 for RS-232C (serial)
• Control 9-pin D-sub x 1 for RS-232C (serial)

• Motorized zoom, focus and lens shift
• Mechanical light shutter

• 1.0:1

• Short zoom 1.5-2.2:1*
• Medium zoom 1.9-3.8:1
• Long zoom 3.6-6.1:1
• Ultra long zoom 6.0-10.3:1

*Lens ships standard

• Horizontal: ± 20 degrees
• Vertical: ± 12 degrees
• 8-point geometry correction

• Power cord (US cord, 1.8m) x 1
• (UK cord, 1.8m) x 1
• (Euro code, 1.8m) x 1
• Computer cable (2m) x 1
• HDMI-DVI cable (0.4m) x 1
• Wireless remote control x 1 & “AA” Batteries x 2
• Security label x 1
• Lens cover x 1
• Adapter cover x 1
• Cable holder x 1
• Network and wireless software (in a CD-ROM)
• User’s manual CD

• Wireless adapter
• Hybrid filter
• 245W UHP lamp

• Crestron RoomView™
• AMX Device Discovery
• 360-degree on axis rotation
• Picture-by-picture
• Dual-stack control
• Digital keystone feature
• Hybrid filter up to 20,000 hours maintenance-free
• Customizable start-up logo
• Selectable aspect ratio 16:9 and true mode
• Intuitive graphical user interface
• Graphical on-screen lens range
• Built-in keypad (power on/standby, menu, up, down, left, right arrows)
• Front and rear infrared sensors for IR keypad
• Supports simple curved screens
• Stackable¹design for redundancy or added brightness
• Built-in security features and menu settings
• Repeatable lens recall capabilities²
• 16W stereo speakers

¹In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.

²Not available on fixed lenses and does not include zoom or focus capabilities.

• Operating voltage: AC100 -120V, 50/60Hz • AC220 -240V, 50/60Hz
• Operating current: 3.8A max at 100V AC • 1.9A max at 220V AC
• Consumption: • 375W  AC100 -120V • 355W  AC220 -240V
• Dissipation: 1280 BTU/hr @ 100-120V • 1212 BTU/hr @ 220-240V

• Body: (LxWxH): 18.7 x 19.6 x 5.8" (476 x 498 x 147mm) (with standard lens)
• Shipping size: (LxWxH): 26.9 x 21.7 x 9.0" (683 x 552 x 229mm)
• Weight: 18.7 lbs (8.5kg) (with standard lens)
• Shipping weight: 27.1 lbs (12.3kg)

• Noise: Standard mode: 35 dBA / 29 dB Eco mode
• Temperature: 32-104°F (0-40°C)
• Humidity: 10-85% non-condensing

• This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC)
• FCC, Part 15, Subpart B, Class
• EN55022/CISPR22 Class A
• EN55024 / CISPR24
• IEC 60950-1
• UL 60950-1
• CAN/CSA C22.2 No. 60950-1
• Directive (EC) 2002/95/EC (RoHS)
• Directive 2002/96/EC (WEEE)
• EU Regulation (EC) No. 1907/2006 (REACH)
• Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), C-Tick (Australia and New Zealand), South Africa
