| Image |
- 4000 ANSI lumens
- 2000:1 (Full on/off)
|
| Display Technology |
- 3 x 0.59” inorganic LCD
- WXGA 1280 x 800 resolution
- 245W UHP lamp
|
| Signals Compatibility |
- SDTV: 480i, 480p, 576i,576p • HDTV: 720p @ 50/60Hz, 1080i @ 50/60Hz, 1080p @ 50/60Hz
- VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA, MAC 16"
|
| Scan Rates |
- 27-162 MHz (see user’s manual for detail information)
|
| Inputs, Controls and Networking |
- Video Input: S-video – Mini Din 4 pin x 1; Composite video – RCA x 1; Component video – RCA x 3
- Audio Input: 3.5 mini x 2 RCA x 2 (L/R)
- Computer Input: D-sub 15 pin x 1
- HDMI Input: HDMI x 1 (HDCP compliant)
- USB: USB type A x1 for PC-Less presentation; USB type B x 1 for USB display or mouse control
- LAN: RJ45 x 1 wired network
- Microphone input: Mono 3.5 mini x 1 (Dynamic and unbalanced microphone)
|
| Optical system |
- Standard lens included – 1.7 x zoom lens
- Manual zoom and focus (1.5-2.5:1 throw ratio)
- Vertical lens shift Up/Down ± 60%
- Horizontal lens shift left/right ± 10% (calculations based on center lens center image using standard zoom lens)
|
| Standard lens |
- 1.5-2.5:1 throw ratio, zoom and focus
|
| Digital keystone |
- Automatic and manual keystone
- Horizontal: ±30 degrees • Vertical: ±30 degrees*
*3D digital keystone (geometry correction).
|
| Standard accessories |
- Computer cable
- Remote control
- Lens cover
- Power cord
- User manual
- Security label
|
| Optional accessories |
- Lamp (003-120730-XX)
- Hybrid filter (003-004239-XX)
|
| Enhanced feature sets |
- AMX Device Discovery; blackboard/whiteboard mode
- Daytime mode
- 3D Keystone geometry correction
- Closed caption (NTSC and component 480i only)
- Stackable*
- Text message capabilities via network
- 16W mono speakers
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.
|
| Power requirements |
- operating voltage: 100-120 VAC ±10%
- 200-240 VAC ±10%
- operating current: 50A @ 100-120V
- 100A @ 220-240V
- consumption: 380W AC100-120V @ 50/60Hz • 360W AC220-240V @ 50/60Hz
- dissipation: 1292 BTU/hr @ 100-120V • 1224 BTU/hr @ 220-240V
|
| Dimensions (LxWxH) |
- (LxWxH): 12.5 x 15.8 x 4.6" (318 x 401 x 118mm)
- shipping size • (LxWxH): 16.5 x 22.0 x 7.8" (420 x 560 x 197mm)
- weight • 10.6lbs (4.8kg)
- shipping weight • 18.1lbs (8.2kg)
|
| Operating environment |
- Standard mode: 36dBA
- Eco mode: 30dBA
- Temperature: 41-95°F (5-35°C)
- Humidity (non condensing): Operating 10-85%, Storage 10-85%
|
| Regulatory Approvals |
- This product conforms to the following regulations related to product safety, environmental requirements
and electromagnetic compatibility (EMC) • FCC, Part 15, Subpart B, Class A • EN55022/CISPR22 Class A • EN55024/CISPR24
• IEC 60950-1 • UL 60950-1 • CAN/CSA C22.2 No. 60950-1• Directive (EC) 2002/95/EC (RoHS) • Directive 2002/96/EC (WEEE)
• EU Regulation (EC) No. 1907/2006 (REACH)
• Certifications marks (check with Christie for latest update): cULus (Canada and the US), CE (EU), CCC (China), GoST-R (Russia),
C-Tick (Australia and New Zealand), South Africa
|
| Limited Warranty |
- Projector: three years parts and labor
- Lamp: 500 hours or one year (whichever comes first)
- Contact an authorized Christie representative for full details of our limited warranty
|
