| Brightness |
- 7,300 ISO
- 7,000 Center
- 6,500 ANSI (typical)
|
| Contrast |
- 300,000:1 with Christie RealBlack enabled
- 250:1 ANSI (nominal)
|
| Display |
|
| Resolution |
|
| Illumination |
- Solid state (laser phosphor)
|
| Lamp Life |
|
| Inputs |
- HDMI x 2
- 3GSDI x 1 (BNC)
- DVI-D x 1 (digital only)
- VGA (HD15) x 1
- USB x 1 (type B mini) - display over USB
- USB x 1 (type A) - image viewer or WiFi dongle (optional)
- HDBaseT x 1
- Ethernet (RJ45) x 1
|
| Signals |
- HDTV formats VGA through to WUXGA (1920 x 1200)
|
| Pixel clock |
|
| Scan rates |
- Horizontal: 15kHz to 91kHz
- Vertical: 24Hz to 85Hz
|
| Monitor out |
|
| Networking |
- RS-232 in
- Control via HDBaseT
- Ethernet (10/100) RJ45 with ChristieNET connectivity
- Built-in backlit keypad
- Wired remote control (3.5mm stereo)
- Loop out available for daisy chaining
|
| Standard accessories |
- IR remote with wired remote jack (wire not included)
- AC line cord for projector head
- Rear input/keypad panel cover
- User manual
|
| Optional accessories |
- QwikRig Frame
- Christie One Mount Plus (140-117100-XX)
- One Mount Extender Rod
- One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
- Wireless dongle
|
| Lens mount |
- Tool-free lens insertion system
- Boresight adjustable
- Motorized horizontal and vertical lens offset
- Motorized zoom and focus adjustment
|
| Lens options |
- 0.75-0.95:1 Zoom lens (140-119102-XX)
- 0.95-1.22:1 Zoom lens (140-101103-XX)
- 1.22-1.52:1 Zoom lens (140-100102-XX)
- 1.52-2.89:1 Zoom lens (140-102104-XX)
- 2.90-5.50:1 Zoom lens (140-107109-XX)
|
| Offsets |
- +/- 100% vertical (+/- 600 px)
- +/- 30% horizontal (+/- 288 px)
|
| Dissipation |
- 2608.7 BTU/hr ±15% (220V)
- 2693.9 BTU/hr ±15% (110V)
|
| Audible noise |
- 35dB(A) standard mode
- 32dB(A) eco mode
|
Dimensions
(L x W x H) |
- Physical: 20.04 x 18.90 x 7.01" (509 x 480 x 178 mm) without feet
- Shipping: 30.12 x 23.35 x 14.37"
|
| Weight |
- Physical: 50.0 lbs (22.6 kg)
- Shipping: 59.5 lbs (27.0 kg)
|
| Operating environment |
- Temperature: 0 to 40°C (32 to 104°F)
- Humidity: 0 to 90% non-condensing
|
| Regulatory |
- Contact Christie for timing of certifications: UL/CSA/IEC 60950-1
- FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS, VCCI, RCM,UKR, TER, SASO
- This product conforms to all relevant European directives, standards, safety, health and environmental concerns RoHS, REACH and WEEE.
|
| Limited warranty |
- 3 years parts and labor on the projector
- 3 years or 15,000 hours parts and labor on the illumination system*
- Contact an authorized Christie representative for full details of our limited warranty
|
