DANE TECHNICZNE
Panel
Diagonal Size75"
Type120Hz Direct LED
Resolution3840*2160 (4K UHD)
Pixel Pitch(mm)N/A
Active Display Area(mm)N/A
Brightness(Typ.)300 (w/o Touch Glass) nit
Contrast RatioMega
Viewing Angle(H/V)178:178
Response Time(G-to-G)8ms
Display ColorsN/A
Color GamutN/A
Operation Hour16/7
HazeN/A
Sound
Speaker TypeBuilt in Speaker (10W x 2) (Down Firing w/Bass Reflex)
Connectivity
Input
RGB-
VideoHDMI Rear1, HDMI Rear2 (ver 2.0), HDMI Front3 (ver 1.4), DVI-D
HDCPN/A
Audio-
USBUSB 1, 2 (Rear), USB 3 (Front), PC USB (Front)
Output
RGB-
Video-
AudioAudio
Touch OutTouch Out 1 (Rear), Touch Out 2 (Front)
Power OutN/A
External ControlRS232C(in/out) thru stereo jack, RJ45, Wi-Fi
External SensorIR Sensor(Display Control)
TunerN/A
Touch
TypeIR (Infra Red)
# of Drawing4 drawing (SoC), 10 drawing (External Windows PC)
Touch Pen TypePassive Pen
Object Recognition Range8mm
Touch Response Time7ms
Power
TypeInternal
Power SupplyAC 100~240V 50/60Hz
Power Consumption
Max[W/h]N/A
Typical[W/h]N/A
BTU(Max)N/A
On mode [W]220(Max), 157(Typical), 200(Rating)
Sleep mode0.5
Off modeN/A
Mechanical Specification
Dimension (mm)
Set1741.5 x 1012.1 x 81.2
Package1905 x 1175 x 307
Weight (kg)
Set57.4
Package69.5
ColorBlack
VESA Mount (mm)400 x 400
Protection GlassYes
Stand TypeWall Mount
Media Player Option TypeN/A
Power Cable Length3m
AccessoryPen Holder
Bezel Width (mm)N/A
Operation
Operating Temperature0 ℃ ~ 40 ℃
Humidity10 % ~ 80 %
Feature
Key FeaturesSlim & Light LFD with Built-in MagicInfo Player S5, SSSP
Special Features
H/WSuper Clear Coating, Temperature Sensor, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded
S/WMagicIWB S5
PlatformKant-M (Tizen 3.0)
Internal Player
ProcessorCoretex A72 1.7GHz Quad-Core CPU
On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
Clock Speed1.7GHz Quad-Core CPU
Main Memory Interface3GB 3ch 64bit LPDDR4 1.6GHz
Graphics2D & 3D Graphic Accelerator Data Format : 32bpp Output resolution : 3840x2160p
Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)
MultimediaVideo Decoder - MPEG 1/2/4, H.263, H.264/AVC - UHD H.264/AVC, VC-1, AVS/AVS+, MVC - VP8, VP9, HEVC, JPEG Audio DSP(Decoder) - MPEG, AC3, AC4, DD, MP3 and etc
IO PortsUSB 2.0
Operating SystemTizen 3.0 (VDLinux)
Accessory
IncludedPassive Pen, Power Cable
