Dane techniczne:
NOMINAL IMPEDANCE
6 Ohms
SENSITIVITY
89dB (at 1m on axis for an input of 2.83v)
FREQUENCY RESPONSE
60Hz - 20kHz (±6dB)
CROSSOVER FREQUENCIES
3.8kHz
DRIVE UNITS
HF: 25mm(1in.) Fluid Cooled Aluminium
LF: 130mm (5.25in.)
RECOMMENDED AMPLIFIER POWER
10-100W
TRANSFORMER TAPS
70V: 3.75W, 7.5W, 15W, 30W
100V: 7.5W, 15W, 30W, 60W
PRODUCT EXTERNAL DIMENSIONS
H x W x D
262 x 197 x 189 mm (10.3 x 7.75 x 7.4 in.) Cabinet only
262 x 197 x 235 mm (10.3 x 7.75 x 9.25 in.) With bracket and knobs
NET WEIGHT
3.3kg (7.25lbs)
UNIT MEASUREMENT
Pair
DOCUMENT DOWNLOAD
Ci Series Pamphlet
Outdoor series brochure
Information sheet
User Manual
EASE GLL Data
Product drawing Ci Series Specifications Sheet
REMARKS
Ventura 5T Independent test laboratory certified IP65. GP Acoustics (UK) Ltd, reserve the right, in line with continuous research and development, to amend or change the specifications without prior notice. E. & O.E.
