Resolution |
2048 x 2048 pixels |
Pixel pitch |
0,246 x 0,246 mm |
Active screen area |
503.8 x 503.8 mm (19.83 x 19.83") |
Active screen diagonal |
712.4 mm (28.05") |
Pixel arrangement |
RGB vertical stripe |
Pixel defect |
zero bright dot |
Backlight |
Edge LED backlight system |
LED lifetime |
> 100,000 hours |
Brightness |
150 cd/m² calibrated and stabilized
Uncalibrated brightness typical 375 cd/m² |
Backlight Output Stabilization (BLOS) |
yes (real-time feedback loop through continuous measurement)
Backlight aging compensation |
Dimming ratio |
100:1 (wrt the calibrated 150 cd/m² => as low as 1,5 cd/m²) |
Contrast ratio |
Typically 1500:1 - ratio of white/black image ; min 1200:1 |
Noise Level |
NA
passive cooling only |
Display colors |
16.7 Mio (24bit) |
Color temperature |
Adjustable between native, D65 and custom |
Viewing angle |
Superwide viewing angle performance
178 ° typical, with CR greater than or equal to 10 |
Uniformity |
White brightness uniformity 80% (min)
Black brightness uniformity 60% (typ) |
Reflection |
Close to zero reflection due to NO front glass |
Front glass |
Optional |
Response time |
Tr (black to white transition): 10 ms, typical
Tf (white to black transition): 8 ms, typical |
Video inputs |
4 digital input connectors
2 x DVI-D Dual link
2 x DisplayPort |
Digital multisync |
Support standard VESA resolution lower than its maximum resolution
Resolutions lower than native which will be displayed in letterbox format
Graphic cards scale up is supported (showing low resolution boot content on full 2K LCD surface) |
Analog RGB |
Connector type: 5 x BNC
Termination: R,G,B: 50 Ohm; HS, VS: 75 Ohm
Sony DDM compatible resolution: 2048 x 2048 - 60Hz ; HF: 126.84 kHz
Automatic Phase Adjust (APA) |
Power Supply |
Nominal voltage: 110 Vac & 230 Vac
Operates between: 90-264 Vac
Frequency range: 47-63 Hz |
Power consumption |
Pacc is typ 31 Watt (in typical area control center setting: 70 cd/m2)
Pnom is typ 41 Watt (stabilized at 150 cd/m2)
Pmax is typ 70 Watt (when Backlight Stabilization is OFF: +375 cd/m2)
Power connector type: IEC
Power consumption low DPMS: 1.9 Watt (monitoring all digital inputs)
Power consumption soft off: 0.5 Watt |
Control possibilities |
Front control module controls multi-language On Screen Display
Remote serial control (full 9 wire RS-232 compatible) for Barco protocol & color measurement equipment
Remote serial DDM Protocol (RS422 on DSUB 15 pin connector)
Network - DHCP / Stat IP / SNMP / Webinterface
Integrated USB hub
-USB upstream port (1x)(connects workstation)
-USB downstream port (2x) (connects pheriphical devices)
GPIO - general purpose input/output (3 input / 3 output, open collector) |
Options |
Protective front filter glass. (Front glass with high-quality anti-reflective treatment - specular reflection less than 1.0%)
(Standard ISIS/4 has no front glass installed - EMI performance level B; LCD display hardness 3H)
Dual Power supply support - internal
Analog inputs RGB HS VS |
Desktop version |
HxWxD: 585x561x135mm
Bezel width:
-top: 39mm
-bottom: 39mm
-left: 27mm
-right: 27mm |
Mounting |
VESA 100x100 and 200x100, M4 |
EMI / EMC |
EU/IEC/Canada/FCC: limit B |
Safety |
IEC60950-1, EN60950-1, UL60950-1, cUL60950-1 |
Operating temperature |
10°C to 40°C (50°F to 104°F) |
Humidity |
85% at 35°C non-condensing atmosphere (operational and non-operational) |
